Model: CAMEDIA C-4000ZOOM
Type: Digital camera with 4.5 cm/1.8 inch colour TFT LCD monitor.
Effective pixel number: 4.0 million pixels. (The actual number of pixels used in image processing.)
Storage media: Removable 3 V (3.3 V) SmartMedia (SSFDC) card (4, 8, 16, 32, 64 and 128 MB).
One 16 MB card with panorama function is supplied with camera.
Number of storable frames with 16 MB SmartMedia card: 1: TIFF 2,288 x 1,712
1: TIFF 2,048 x 1,536
2: TIFF 1,600 x 1,200
4: TIFF 1,280 x 960
6: TIFF 1,024 x 768
6: TIFF 640 x 480
1: TIFF 2,288 x 1,520 (3:2)
2 or more: SHQ 3,200 x 2,400*
5 or more: SHQ 2,288 x 1,712
6 or more: SHQ 2,288 x 1,520 (3:2)
8 or more: HQ 3,200 x 2,400*
16 or more: HQ 2,288 x 1,712
18 or more: HQ 2,288 x 1,520 (3:2)
6 or more: SQ1 2,048 x 1,536 (High)
20 or more: SQ1 2,048 x 1,536 (Normal)
11 or more: SQ1 1,600 x 1,200 (High)
32 or more: SQ1 1,600 x 1,200 (Normal)
17 or more: SQ1 1,280 x 960 (High)
49 or more: SQ1 1,280 x 960 (Normal)
26 or more: SQ2 1,024 x 768 (High)
76 or more: SQ2 1,024 x 768 (Normal)
66 or more: SQ2 640 x 480 (High)
165 or more: SQ2 640 x 480 (Normal)
* Print enlarge mode.
Compression ratio: 1, 2.7, 8.
Recording system: Still image: JPEG (DCF: "Design rule for Camera File system"), TIFF (non-compress), DPOF support.
Motion picture: QuickTime Motion JPEG®*.
Imager: 1/1.8 inch CCD solid-state image pickup with 4.13 million pixels.
White balance: Full-auto TTL (iESP II), pre-set (daylight, overcast, tungsten light, fluorescent
light 1, 2 & 3, One touch. White balance compensation possible.
Lens: Olympus 3x multivariator zoom lens 6.5 ? 19.5 mm, F2.8 (equivalent to 32 ? 96 mm lens in 35 mm format.) 8 lenses in 6 groups (2 aspherical lenses).
Digital zoom: Smooth 1x ? 3.5x.
Light metering: Digital ESP metering system with imager. Spot metering. Multi-spot metering.
AE lock possible, exposure area selection, histogram in shooting mode.
Exposure control: Programmed auto exposure, Aperture priority auto and Shutter priority auto.
Exposure compensation in ±2 EV in ±1/3 EV steps
Programmed auto: F2.8 ? F11, 16 ? 1/1000 sec.
Manual exposure: shutter speed up to 16 sec. Noise reduction used for shooting speeds below 1 sec.
Aperture priority: F2.8 ? F11, 1/3 EV steps.
Shutter priority: still image: 16 ? 1/1000 sec. (with mechanical shutter), 1/3 EV steps.
AE lock possible.
Scene Programmes: Full Auto, Landscape, Self-portrait, Night Scene, Sports, Landscape-Portrait and Portrait.
QuickTime Motion JPEG image mode: 1/30 ? 1/10,000 sec.
Auto bracketing: selectable from 1/3 EV, 2/3 EV and 1 EV. Max 5 images.
Focusing: TTL system iESP autofocus (contrast detection system).
Focusing range: 0.2 m ? infinity.
Manual focus with gauge with focusing range 0.2 m -? infinity.
Working range: Standard mode: 0.8 m ? infinity.
Macro mode: 0.2 ? 0.8 m.
Super Macro: 0.02 ? 0.2 m.
Sensitivity: Auto or manual adjustment. Selectable from approx. equivalent to ISO 100, 200 and 400.
Viewfinder: Optical real-image, LCD monitor.
LCD monitor: 1.8-inch colour TFT LCD monitor with 110,000 pixels made of low-temperature
poly-silicon. Brightness adjustment is possible.
Flash: Built-in flash.
Flash modes: Auto (automatic activation in low and backlight), Red-eye reduction, Off (no flash),
Fill-in (forced activation), Slow synchronisation. (first-curtain synchronisation effect, second-curtain synchronisation effect).
External terminal: Off, Auto, Forced activation.
Flash working range: Wide: approx. 0.8 ? 3.6 m; tele: approx. 0.2 ? 3.6 m (ISO 100).
Flash recycle time: Less than 6 sec. (at normal temperature with new batteries).
Sequence mode: Up to 8 frames at up to 1.5 shots per sec in HQ mode (excluding TIFF mode).
Motion picture mode:
w/ 16MB SmartMedia card Format: QuickTime Motion JPEG*.
HQ: Up to approx. 33 sec., 320 x 240 pixels, 15 frames/sec.
SQ: Up to approx. 148 sec.,160 x 120 pixels, 15 frames/sec.
Function shooting: 2 in 1 / Crop and Merge function.
Playback function: Close-up, Index (4, 9, 16 frames in a page), Rotation (using video output terminal).
Image effect: Sepia mode, black & white mode, blackboard mode, whiteboard mode.
Still image edit Resize, Cropping
Motion picture edit Cut, index.
Image processing: TruePic, noise reduction.
DPOF setting Print reservation, all print reservation, date/time, trimming.
Self-timer Approx. 12 sec. delay.
Multilingual menu: English, French, German, Spanish.
Outer connector: DC input terminal, USB interface (AutoConnect), video output terminal (PAL), and External flash terminal for FL-40 (5pin type).
Operating environment: Temperature: 0 ? 40°C (operation); -20 ? 60°C (storage).
Humidity: 30 ? 90% (operation); 10 ? 90% (storage).
Power supply: Main power source: 4 x AA Ni-MH or 4 x AA Ni-Cd rechargeable batteries, or 2 x lithium batteries LB-01 (CR-V3), 4 x AA lithium batteries, 4 x AA alkaline batteries.
(Zinc carbon (manganese) batteries cannot be used.) Optional AC adapter (6V).
Date/time/calendar: Simultaneous recording onto image data.
Automatic calendar system: Up to year 2031.
Dimensions: 109.5 (W) x 76.5 (H) x 66.5 (D) mm (excluding protrusions).
Weight: 295g (without batteries and Smart Media card).
