http://davidweikel.com/E10_samples/tcon300/tcon1.shtml
http://www.steves-digicams.com/2001_reviews/e20n.html
Innovations like the ability to shoot in both the Interlaced and Progressive scan modes, Auto-Connect USB, and Olympus' own TruePicTM technology helps the E-20N to meet many, if not all, of your photographic needs in a 15MB file.
Unleash the full potential of the E-20N using these included contents: a Lens Hood; Lens Cap; Video Cable; USB Auto-Connect Cable; Strap; 2 x LB-01 (CR-V3)Batteries; RM-1 Wireless Remote; 32MB SmartMedia Card; User Registration Card; Limited Warranty ((US/Canada/Latin America/South America); Basic Manual; CAMEDIA Master software (Macintosh/Windows); Windows 98//98SE USB Driver and Installation Guide; Adobe Photoshop Elements v1.0 (Macintosh/Windows);
FEATURES:
• Auto-Connect USB (Storage Class USB) Windows® XP and Macintosh® OSX ready
• Dual Card Slots: SmartMediaTM, CompactFlashTM Type I and II; and IBM MicrodriveTM support
• Faster playback and review capabilities than previous Olympus models
• TruePicTM technology helps produce smooth and true photographic images
• Noise Reduction assists in providing clear, clean images in long exposures
• PC Flash Sync for Studio and PC Sync flashes
• Adjustable LCD monitor can be viewed at angles of 20-, 0-, or 90-degrees, or in the automatic or manual mode
• User-selectable Auto White Balance, 7 Pre-set White Balances from 3000K to 7500K, and one-touch manual white balance
• Compatible with all Olympus E-10 accessories
• CCD Imager 2/3 in. (.66 in.) CCD solid-state image pickup 5.0 Megapixel (effective)
• 5.2 Megapixel (total CCD resolution)
• RGB Interlaced/Progressive scan CCD
• Lens Olympus lens 9 ? 36 mm 2.0 - 2.4, ED Glass Aspherical Zoom Lens
• Fully Multicoated (all elements)
• 2 Aspherical Glass elements and Gauss Lens group (Equivalent to 35 - 140 mm lens on 35 mm camera)
• Optional 0.8x (wide) 1.45x, 3x (telephotos)
• Aperture Range Wide F2.0 ? 11; Tele F2.4 ? 11, 1/3EV steps
• Shutter Speeds 2 - 1/640 sec. (used with mechanical shutter), 1/3EV steps manual exposure to 60 sec. and Bulb to 8 min. Interlaced scan mode IS// 2 sec to 1/4000 sec. and 1/18000 sec. (used with CCD shutter), 1/3 EV steps Manual exposure to 60 sec. and Bulb to 8 min..P
• Recording Mode(s) Still image:EXIF, JPEG (DCF: "Design rule for Camera File system"), TIFF (non-compress), DPOF support RAW (16 bit per color) ? Ships with Photoshop Plug-in for RAW
• 10 Bit A>D Converter
• Adjustable Resolutions 2560 x 1920 (RAW/TIFF/JPEG-SHQ/HQ/SQ), 1792 x 1344 (PS.JPEG-SHQ/HQ/SQ), 1280 x 960 (JPEG-SHQ/HQ/SQ), 1024 x 768 (JPEG-SHQ/HQ/SQ), 640 x 480 (JPEG-SHQ/HQ/SQ) (JPEG Compressions of 1:2.7, 1:4, and 1:8 are avalible in SHQ, HQ, and SQ modes)
• DPOF (Digital Print Order Format) "Print" Reserve, All print reservation, Date/time
• Image Adjustment Modes Contrast: Low, Normal, High (User selectable in menus)
• Sharpness: Soft, Normal, Hard (User selectable in menus)
• Sequence 2.5 frames per sec. up to 3 frames TIFF; 4 frames RAW IS mode: 4.5 frames per sec. to 7 shots in PS JPEG mode
• 1 second shot to shot
• Viewfinder SLR optical viewfinder (Full Information / Mode / Aperture / Shutter Speed / Spot / Center Weighted / digital ESP / +/-/ AF / Flash)
• 95% V/H accurate Focusing screen (shows focus)
• LCD 4.5 cm / 1.8 in. wider angle color TFT LCD monitor with 114,000 pixels (made from low-temperature poly-silicon), brightness adjustment is possible
• Adjustable 20, 0, 90 Degrees (click stops) 95% accurate area-view of subject
• Focusing System Dual AF-Active (IR and Passive TTL) system autofocus (contrast detection system) with focusing range: 8 in. - infinity / 0.2 m - infinity, stepless
• Manual focus (manual focus setting by gauge) with focusing range: 8 in. - infinity / 0.2 m ? infinity
• Focusing Ranges Standard mode: 0.6m ? infinity
• Macro mode: 8 in. - 30 in. / 0.2 ? 0.8 m
• Exposure Control Programmed auto exposure, Aperture priority, Shutter priority
• +/- 3Ev by 1/3EV steps exposure compensation
• Auto Bracketing: selectable from 1/3EV, 2/3 EV and 1EV; 3 or 5 images
• Aperture priority: Wide F2.0 ? 11, Tele F2.4 ? 11, 1/3EV ste
• Metering System Digital "ESP" Multi-Pattern metering system
• Center-weighted metering
• Spot metering
• White Balance System iESP full-auto TTL,
• 7 stage Preset Manual (3000; 3500; 4000; 4500; 5500; 6500; and 7500 K)
• One Touch Manual (Set by White Card)
• Flash Built-in flash
• External Flash Modes Built-in: Auto-Flash (low-& back-light), Red-Eye Reducing Flash, Off, Fill-in
• External terminal: Off, Auto, Forced activation (Flash Sync to 1/640 sec.)
• Slow Synchronization (First-Curtain Synchronization effect, Second-Curtain Synchronization
• Flash Working Range Wide: approximately 0.8 m ? 5.6 m
• Telephoto: approximately 0.2 m ? 3.8 m (ISO 100)
• Flash Charging Time Less than 6 sec. (at normal temperature with new battery)
• Removable Media Card 3V (3.3V) SmartMedia™ (SSFDC) Card (2MB, 4MB, 8MB,16MB, 32MB and 64MB)
• Setting Memorization Possible
• Outer Connectors DC input terminal, Data input/output terminal (RS232C), USB interface
• Video Output terminal (NTSC), external flash PC terminal, Hotshoe (FL-40TTL)
• Image Playback One frame display
• Index-display mode (4/9 frames)
• Close-up display (2.0x)
• Slide show playback supported
• Histogram and Picture information File number display in play back mode possible
• Operating Environment Temperature: 0º - 40ºC (operation); -20º - 60°C (storage) Humidity: 30 - 90% (operation); 10 ? 90% (storage)
• Power Supply Main power source: 2 x lithium battery CR-V3 / Optional LBS30 or LBS32 LiPo Battery with Grip Kit / 4 x AA Ni-MH batteries / 4 x AA Ni-Cd batteries/ 4 AA Alkaline batteries can be used for emergency power
• Optional 7AU-AC adapter
• Date/Time Calendar Simultaneous recording onto image data
• Calendar Up to year 2030
• Number of Storable Photos With 32MB SmartMedia Card:
• 2: TIFF 2560 x 1920
• 3: RAW 2560 x 1920
• 7: SHQ 2560 x 1920 (2.7:1 JPEG)
• 31: HQ 1792 x 1344 (8:1 JPEG)
• Total of 15 JPEG modes at 2.7:1, 4:1 and 8:1 compressions, [640 x 480; 1024 x 768; 1280 x 960, 1792 x 1344, 2560 x 1920] user selectable.
